XGS-PON Bridge ONT — ZXHN F2801S
The ZXHN F2801S is an XGS-PON bridge ONT that provides one 2.5 Gigabit LAN port. It is ideal for FTTH or small business deployments in bridge mode. The ZXHN F2801S provides a 2.5GE interface to connect PCs or notebooks and can work with an RG to provide service assurance for video and high-speed Internet access.
Product Highlights
- 2.5 Gigabit LAN Port
- · XGS-PON and 2.5GE LAN bring unappalled 2.5 Gbps bandwidth experiences.
- More Flexible Management
- · Software upgrade and management via the EMS/OLT
· Fault analysis, port loopback, and link detection via the OMCI
- High Reliability
- · Highly reliable heat dissipation design ensures stable operation.
· Dual image ensures uninterrupted services during software download or upgrade, enhancing software reliability.
Product Parameters
- WAN
- XGS-PON
- LAN
- 1 x 2.5GE RJ-45 port
- Buttons
- Power On/Off, Reset
- Power Supply
- AC adapter: 12 VDC, 0.5A
- LEDs
- Power, PON, Alarm, Update, 2.5G LAN
- Dimensions (W x H x D)
- 108 x 103 x 28 mm
- Operating Temperature
- 0℃ ~ +40℃
- Humidity
- 5% - 95% (non-condensing)
- Certification
- CE certification
